SINTERED PE FILTER SHEET 500X500X4 20MICRON

DALON’s 20µm porous plastic sheet filter is a precision-engineered sintered polyethylene (PE) filtration medium designed for air, gas, and non-pressurized fluid applications. Measuring 500 mm × 500 mm × 4 mm, this flat sheet delivers a uniform 20-micron nominal pore structure, making it ideal for airflow filtration, dust shielding, enclosure venting, and pre-filtration in sensitive systems.

Manufactured using DALON’s ISO 9001:2015-certified process, the porous structure of this PE sheet enables consistent particle retention while maintaining stable airflow and mechanical integrity. It can be die-cut, laser-trimmed, or thermoformed into custom shapes, making it highly adaptable for OEMs in industrial automation, electronics, medical devices, and smart sensing equipment.

Key Features

• Filtration rating: 20 microns (nominal)

• Dimensions: 500 mm × 500 mm × 4 mm

• Material: Sintered polyethylene (PE)

• High airflow with consistent particle control

• Lightweight, chemically inert, and UV/moisture resistant

• Customizable in shape, thickness, and surface treatment

Applications

• Air and dust filtration in enclosure systems

• Sensor vent protection and weatherproof housings

• Vent panels in automation cabinets and HVAC units

• Environmental sealing in IoT, automotive, or electronic modules

• Pre-filtration for non-pressurized fluid tanks or drains

• Prototype media for filter development and customization

Why Choose DALON

DALON is a global supplier of sintered plastic filter sheets trusted by OEMs in electronics, laboratory instruments, ventilation systems, and environmental sensing. All filter sheets are produced to strict tolerance standards for repeatable pore uniformity, excellent mechanical performance, and chemical stability. Custom sheet thicknesses, micron ratings (5–100µm), and hydrophobic/hydrophilic treatments are available upon request.

Whether for venting, screening, filtering, or pressure balancing, DALON’s porous PE sheet filters deliver reliable and adaptable solutions for demanding environments.

FAQ – Frequently Asked Questions

Q1: What does a 20µm porous PE sheet filter block?
It blocks fine dust, airborne particles, and fluid impurities above 20 microns, ensuring clean air or pre-treated fluid flow.

Q2: Can I cut or shape this sheet for custom applications?
Yes. The sheet can be easily trimmed using CNC, laser, or manual tools to fit your design or device requirements.

Q3: Is it suitable for liquid filtration?
Yes. While commonly used for air or gas, it can be used in low-pressure fluid applications such as reservoir vents or sediment screens.

Q4: Can the material withstand outdoor use?
Absolutely. Sintered PE is UV-resistant, water-stable, and chemically inert—perfect for both indoor and outdoor sensor protection.

Q5: Is this filter sheet reusable?
Yes. It can be cleaned with water, air, or mild solvents depending on the media it was exposed to.

Q6: What industries use this filter type?
Used in environmental monitoring, HVAC systems, electronic enclosures, medical sensors, IoT devices, and smart meter housings.
