Premium Quality Sintered Bushing
| I.D.(d) | 10 |
| I.D. (d1) | |
| O.D. (D) | 14 |
| O.D. (D1) | |
| Length (L) | 10 |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | F7 r7 js13 |
| Weight(ref)/Gram | 4.90 |
| Minimum Order Qty | 40KGS |
DALON’s 10×14×10 mm sintered bronze bushing is a precision-engineered brass bearing bushing designed for low-friction rotary or linear motion. Manufactured using powder metallurgy, this self-lubricating bushing provides consistent performance in dry-running or marginally lubricated environments.
Its compact form, with an inner diameter of 10 mm, outer diameter of 14 mm, and length of 10 mm, makes it ideal for tight-space applications such as electric motors, gearboxes, pumps, and household appliances. The porous bronze matrix absorbs lubricant and releases it during operation, minimizing maintenance and wear.
Size: 10 mm ID × 14 mm OD × 10 mm Length
Material: Sintered bronze (Cu90Sn10 or equivalent)
Self-lubricating: No external oil or grease required
Uniform porosity for consistent lubricant retention
High dimensional stability and load-bearing capacity
Silent, maintenance-free operation in rotational systems
Small motors and fans
Power tools and garden equipment
Household appliances (vacuum, blenders, etc.)
Office machines and printers
Compact gear assemblies and transmission modules
DIY and hobbyist mechanical projects
As a certified ISO 9001:2015 manufacturer, DALON produces sintered bronze bushings for OEMs worldwide. Our brass bearing bushings are made with advanced powder metallurgy techniques to deliver high precision, long service life, and excellent oil retention.
We offer full customization services for diameter, length, tolerances, and material composition based on your design or load specifications. DALON ensures consistent quality across batches with cost-effective scalability for both prototyping and mass production.
Q1: What does “sintered” mean in this bushing?
It refers to a manufacturing process where bronze powder is compressed and heated just below melting point, forming a porous structure that retains lubricants internally.
Q2: Is this bushing made of brass or bronze?
The term “brass bearing bushing” is often used interchangeably, but this part is made of sintered bronze for superior oil retention and wear resistance.
Q3: Can this bushing be used without lubrication?
Yes. It is self-lubricating and designed for dry-running or semi-lubricated applications, making it maintenance-free under normal conditions.
Q4: What kind of loads or speeds can it handle?
It’s suitable for light to medium loads and moderate speeds. For heavy-duty or high-speed applications, consult DALON for reinforced designs.
Q5: Can this be customized for special fits or tolerances?
Absolutely. We support custom tolerances, lengths, and inner/outer diameters to match specific shaft and housing requirements.
Q6: What industries use this type of bearing bushing?
It’s widely used in motors, tools, small machinery, HVAC systems, electronics, and other mechanical assemblies requiring quiet, low-friction motion.
The versatility of SINTERED BRONZE BUSHING 10X14X10 makes them ideal for numerous applications, including:
SINTERED BRONZE BUSHING 10X14X10 are engineered for demanding applications where traditional lubrication methods are impractical. They provide exceptional performance, durability, and cost-effectiveness, making them the preferred choice across various industries. Experience the reliability and efficiency of SINTERED BRONZE BUSHING 10X14X10, designed to meet your specific application requirements.
